yk80x is the new version of yk80,  updated version , OLED , more precise .



Features and specifications:

Packing List:

1 x Pulse Oximeter

1 x product Manual

1 x Product lanyard



Pulse Oximeter Product features:

One-button measurement

8 seconds without test, device will automatically shut down

Medical clinical level settings

all-day real-time monitoring

sound and light alarm

multi-directional display

screen brightness adjustment

Multi-color optional



Fourth generation LFC technology

The fourth generation of optical frequency digital conversion technology achieves precision

Round light shield

Effectively reduce the impact of natural light on accuracy and improve accuracy

High speed processing chip

Data acquisition and processing are accurate and fast, 5-8s display value

Easy to read

You can adjust the display direction at will, and a variety of display interfaces are available.

Sound and light alarm system

The setting limit is exceeded (settable), the machine sends a reminder

Less than 30g

Small body size and weight, portable lanyard, easy to carry

Automatic Power Off

Remove the finger 10s, the oximeter automatically turns off, saving power

Upgrade wearing experience

Soft skin-friendly silicone pad to protect your fingers during measurement















YK80:

Description:

The Finger Pulse Oximeter is an affordable and accurate way to check pulse rates and blood oxygen saturation levels. It also shows the Plethysmograph wave, which guarantees the accuracy. Self-adjusting finger clamp plus simple one-button design allows for easy operation. Comes with a carrying case and Neck/wrist cord. Convenient for nurse and doctor to hang on the neck. Small portable size makes it easy to handle and carry. Suitable for daily use, measure your health at any time.



Features:

—OLED display:Dual Color OLED display. Better shows the data.



—Multi-direction display:Rotatable multidirectional display. 4 directions, 6 modes, allow you to view your results in any direction.



—Alarm function:Set the alarm and beep according to your needs. There will be a warning once the measured values go beyond the setting. Know it immediately.



—Long battery life: 1) Low-power consumption, continuously work for 6 hours.

2)In the absence ofsignal, the product will be in after 8 seconds to enter standby state.



Notice:

1. Please double check the direction of the battery. The 2 batteries are in different direction, please make the +/- right.

2. The finger should be plugged deep enough, or it can not take the measure

3. Please do not tremble the finger or move the body during the measurement, or the data maybe unsteady.



Package Content

– 1 x Fingertip Oximeter(without battery)

– 1 x Lanyard

– 1 x English user manual



By aviation restrictions,bettaries are not included in the package.



LED M230B

Features

1)  2direction display

2)  parameters: SPO2, PR

3)Low-power consumption,continuously four direction adjustable;

5)  Low voltage indicator;

6)  Automatically power off in 8 seconds when there is no signal;





Specifications

– SpO2

Measurement range: 70~100%

Resolution: ±1%

Accuracy: ±2% (70%~99%), unspecified (70%)

– Pulse rate (PR)

Measurement range: 30~250 bpm

Accuracy: ±1bpm

– Perfusion Index (PI)

Measurement range: 0~30%

Accuracy: ±1%

– Power:1.5V (AAA size) alkaline battery x 2

– Working current: ≤30mA

– Automatic power-of: Automatically power off when no signal in the oximeter for more than 8 seconds

– Environmental Sepecification

Operating Temperature:5-40 degrees ;

Storage/Transportation Temperature:-10 to 40 degrees Celcius;

Ambient Humidity:15-80% on operation;

10%-80% in storage

– Declaration:EMC of this product complies with IEC60601-1-2 standard



Packing list:

– 1 x Pulse oximeter

– 1 x English user's manual  for LED M230B ,

– 1 x Case

– 1 x Landyard



1. The following picture is LED  Model  M230b









By aviation restrictions, batteries are not  included in the package, please usealkaline batteryto run it .
